Features of HG series linear guides:
Self-aligning: The DF(45°-45°) combination from the arc-shaped grooves. During installation, through the elastic deformation of the steel balls and the transfer of the contact points, even if there is a slight deviation in the installation surface, it can be absorbed by the internal structure of the linear guide slider, generating an self-aligning effect and achieving high-precision, stable and smooth movement.
2. Good interchangeability: Due to the strict control over production and manufacturing precision, the size of the linear guide rails can be maintained within a certain level. Moreover, the sliders are designed with retainers to prevent steel balls from falling off. Therefore, the precision of some series is interchangeable. Customers can order the guide rails or sliders as needed, or store them separately to reduce storage space.
3. High rigidity: By using four-row arc-shaped grooves and combining them with four rows of steel balls at a 45-degree contact Angle, the steel balls achieve an ideal two-point contact structure, capable of withstanding loads from both up and down and left and right directions. When necessary, preloading can be applied to enhance rigidity.
4. The high-precision HG series linear guides adopt high-precision processing techniques, ensuring the fit accuracy between the track and the slider, thereby enhancing the accuracy of the entire linear motion system.
5. The HG series linear guides with high load capacity have a large load capacity and can withstand significant axial and radial loads, making them suitable for various heavy-duty applications.
6. Easy installation: The HG series linear guides offer multiple installation methods, which can meet the installation requirements of different equipment.
